Fastener>>IFI Fastener >> ASTM F436



ASTM F436 Hardened Circular,Clipped Circular,and Extra-Thick Washers

ASTM F436 Hardened Circular,Clipped Circular,and Extra-Thick Washers

Circular and Extra Thick
Clipped Circular
Circular,Clipped Circular,and Extra Thick Circular and Clipped Extra Thick Clipped
Nominal Size Nominal Outside
Diameter(OD),in. 		NominalInside
Diameter(ID),in. 		Thickness (T),in. Minimum Edge
Distance (E)A,in.
min max min max
1/4 0.625 0.281 0.051 0.08 … … 0.219
5/16 0.688 0.344 0.051 0.08 … … 0.281
3/8 0.813 0.406 0.051 0.08 … … 0.344
7/16 0.922 0.469 0.051 0.08 … … 0.406
1/2 1.063 0.531 0.097 0.177 0.305 0.375 0.438
9/16 1.188 0.625 0.11 0.177 0.305 0.375 0.5
5/8 1.313 0.688 0.122 0.177 0.305 0.375 0.563
3/4 1.468 0.813 0.122 0.177 0.305 0.375 0.656
7/8 1.750 0.938 0.136 0.177 0.305 0.375 0.781
1 2.000 1.063 0.136 0.177 0.305 0.375 0.875
1 1/8 2.250 1.188 0.136 0.177 0.305 0.375 1
1 1/4 2.500 1.375 0.136 0.177 0.305 0.375 1.094
1 3/8 2.750 1.5 0.136 0.177 0.305 0.375 1.219
1 1/2 3.000 1.625 0.136 0.177 0.305 0.375 1.313
1 3/4 3.375 1.875 0.178B 0.28B 0.305 0.375 1.531
2 3.750 2.125 0.178B 0.28B 0.305 0.375 1.75
2 1/4 4.000 2.375 0.24C 0.34C 0.305 0.375 2
2 1/2 4.500 2.625 0.24C 0.34C 0.313 0.375 2.188
2 3/4 5.000 2.875 0.24C 0.34C 0.313 0.375 2.406
3 5.500 3.125 0.24C 0.34C 0.313 0.375 2.625
3 1/4 6.000 3.375 0.24C 0.34C 0.313 0.375 2.875
3 1/2 6.500 3.625 0.24C 0.34C 0.313 0.375 3.063
3 3/4 7.000 3.875 0.24C 0.34C 0.313 0.375 3.313
4 7.500 4.125 0.24C 0.34C 0.313 0.375 3.5

ASTM F436 Hardened Beveled Washers




Square SquareClipped
Square Beveled and Clipped Square Beveled A
Clipped
Bolt Size, In. Minimum Side
Dimension (A),in. 		Nominal Inside
Diameter(I.D.),in. 		Mean Thickness
(T),in. 		Slopeor Taperin
Thickness 		Nominal Edge
Distance (E),
B in.
1/2 1 3/4 17/32 5/16 1:06 7/16
5/8 1 3/4 11/16 5/16 1:06 9/16
3/4 1 3/4 13/16 5/16 1:06 21/32
7/8 1 3/4 15/16 5/16 1:06 25/32
1 1 3/4 11/8 5/16 1:06 7/8
11/8 2 1/4 11/4 5/16 1:06 1
11/4 2 1/4 13/8 5/16 1:06 13/32
13/8 2 1/4 11/2 5/16 1:06 17/32
11/2 2 1/4 15/8 5/16 1:06 15/16
